JX2-4

3.6m Man Up Electric Order Picker with Forks 1.0 Ton

The EP JX2-4 is the largest man-up order picker in the JX2 series, with 1-tonne capacity, lift heights up to 3.6m and an open platform to provide freedom of movement when picking pallets or boxes. By combining the best features of an order picker, counterbalance truck and pallet truck, the JX2-4 can replace multiple machines in your warehouse.

The JX2-4 is easy to drive and control, with a smooth AC drive system, proportional controls and electronic power steering. Power is provided by a 24V/360Ah lead-acid battery, mounted on a lateral roller bed for rapid battery exchange if required. The operator platform features a padded floor, backrest and overhead guard with multiple safety harness points, ensuring a safe and comfortable working environment.

Versatile and affordable, the JX2-4 is a smart order picking solution for SME warehousing and logistics. It is backed by a two year EP warranty.

DOWNLOAD THE DATA SHEET HERE

If you choose our compact and robust JX2 – you will definitely notice a comfortable and an improvement as your full view allows you to work in a much safer environment and a flexible order picking. JX2 is built to lift up to one ton and the maximum lift height is up to 3620mm.

- 3200mm/3600mm platform height (4800mm/5200mm picking height)
- 1000kg fork capacity
- Service weight 1900kg/1965kg
- 24V/360Ah lead-acid battery with external charger
- Electromagnetic braking
- AC drive system
- Two-year EP factory warranty

Liftrucks New Zealands Warranty coverage on EP Products.

EP takes pride in manufacturing quality equipment. The company guarantees all products to be free of defects in materials and workmanship when equipment is properly operated and maintained during the warranty period.

WARRANTY COVERAGE

2 years or 2000hrs whichever comes first on all mechanical items

2 years or 2000hrs whichever comes first on all electrical items including
batteries (Hoppecke, GS, HAWER)

Please see full warranty details HERE
