J1HD Series

High Level Order Picker

The new J1HD from EP is the tallest man-up order picker on the market, with an ultra-stable triplex mast suitable for pick faces up to 7 metres high. By permitting full use of high-stud warehousing while giving operators the confidence to work efficiently, the J1HD delivers a step change in e-commerce productivity.

The J1HD is available with mast heights of 4.1m or 5.3m, offering pick heights of 5.7m or 7.0m. The efficient AC drive motor is powered by a full-shift 48V/360AH lead-acid battery, mounted on a lateral roller bed for rapid battery exchange. With its smooth electronic power steering, the J1HD can turn around in a 1.6m aisle, and can drive and lift simultanously to minimise standing time.

Stable, safe and competitively priced, the J1HD is an ideal order-picking solution for 3PL logistics and e-commerce retailers, especially in cities with high commercial land prices. The J1HD is backed by a two-year warranty.

DOWNLOAD THE DATA SHEET HERE

The J1HD Super Joey was designed to out-perform ordinary order pickers and utility vehicles in large warehouses and DCs. Based on the best-selling EP JX1 order picker, the J1HD (Super Joey) is a little larger, rises up a lot higher and travels twice as fast. With 210” of lift and a top speed of 7mph, it is able to reach the 4th level of racking and whisk from storage to shipping in record time. Its optional 48V Li-ion power system delivers high-performance travel, lift speed, enhanced duty cycles and extended run-times.

- 4110mm/5330mm platform height (5710mm/6930mm picking height)
- 591kg capacity (136kg operator + 318kg upper load tray + 137kg lower load tray)
- Service weight 1440kg/1630kg
- 48V/360Ah lead-acid battery with external charger
- Electromagnetic braking
- AC drive system
- Two-year EP factory warranty

Liftrucks New Zealands Warranty coverage on EP Products.

EP takes pride in manufacturing quality equipment. The company guarantees all products to be free of defects in materials and workmanship when equipment is properly operated and maintained during the warranty period.

WARRANTY COVERAGE

2 years or 2000hrs whichever comes first on all mechanical items

2 years or 2000hrs whichever comes first on all electrical items including
batteries (Hoppecke, GS, HAWER)

Please see full warranty details HERE
